Items |
Model |
||
|
Maximum paper width |
800mm |
1000mm |
1200mm |
|
Maximum printing width |
780mm |
980mm |
1180mm |
|
Printing repeat |
500-1200mm |
||
|
Maximum unwinding/ rewinding dia |
1500mm |
||
|
Gear format |
5mm per tooth (size different depends on material) |
||
|
The speed |
150-200m/min |
150-200m/min |
150-200m/min |
|
The thickness of tape |
0.38mm |
0.38mm |
0.38mm |
|
Air comsuption |
6KG, 0.6L/Min clear, dry, no water/oil AIR |
||
|
Dry type |
Electric heating, natural gasheating, ect. |
||
|
Film |
Paper |
Non-woven fabric/woven bag |
Carton |
Aluminum foil |
Material |
|
0.012-0.3 mm |
20-100 gs.m, 80-250gs.m, 100-350 gs.m |
15un-400mm |
50-300 gs.m |
Aluminum foil: 10-50um, paper:＜80g |
Thickness off paper |
|
BOPP,PVC,PE,PE film, tissue paper and other roll - like materials |
White card paper, kraft paper, grey white board, coated paper and other roll - like materials |
Non - woven fabric, woven bag, valve pocket, paper, film and other roll - like materials |
Carton preprinted surface paper, backing paper, paper, film and other roll materials |
Aluminum foil, paper, etc |
Material |
|
1.7mm/2.28mm/2.84mm（ The thickness varies according to the material） |
The thickness of plate |
||||
|
Aluminum foil applicable ink: water - based ink, solvent ink and UV ink Printing color group: 1 color -10 color, can meet different customer needs. Minimum color unit： 4 colors |
|
||||
